Product Description
The CFL900 Float level switch from Coleman controls are designed to control pumps, valves, motors, alarms etc in Building Automation and Process Control applications. They are suitable for various kinds of liquids including non corrosive, high temperature, light density or turbulent liquids.
Product Features
| Product ID | CFL009S |
| Contact | SPDT, 10A/250VAC |
| Electrical life | >106 cycles |
| Switch angle | ±40° (±5°) |
| Operating temperature | 0-60°C |
| Storage temperature | -20-80°C |
| Weight | 300g |
| Counterweight | 200g |
| Volume | 498cm3 |
| Materials | float PP; counterweight: ABS |
| Protection | IP68 |
| Max working pressure | 1.2 bar (12m water depth) |
| Approval | CE |
